Abstract
It's a classic
Troubleshooting
Before Starting
2h 40m 45s

Make RIPA buffer (to be used in 3 months after adding Nuclease)
AB
50mM Tris HCl, PH 7.4 5mL (1M stock)
150mM NaCl 5mL (3M stock)
1% Triton X-100 or NP-40 1 mL
0.1% SDS 1mL (10% supply center solution)
1mM EDTA 0.2 mL (0.5M stock)
10mM Naf 0.042g (@L5P1 chemical room)
0.5% Sodium deoxylcholate 0.5g (@L5P1 chemical room)
Add ddH2O to 100 mL
Add PMSF [final] = 1mM and any other protease inhibitors immediately before use
Add 1uL Pierce™ Universal Nuclease per 1mL


SDS Running Buffer
Cell lysis
Trypsinize cells
Wash pellet with PBS
Remove all supernatant with micropipette
Freeze pellet in liquid N2
Thaw quickly at Temperature37 °C

Resuspend cell pellet on buffer Amount100 µL

Vortex Duration00:00:15

15s
Incubate on Ice Duration00:20:00

20m
Vortex Duration00:00:15

Collect supernatant
Centrifuge 10000 RPM for Duration00:05:00

5m
Running, Transfer and Blot
2h 40m 45s
Collect supernatant without disturbing the pellet
Quantify protein
799 uL water + 1 uL lysate
+ 200 uL 5x Bradford reagent
Read at 595 nm
Load 50 µg of protein/well
Loading buffer Amount50 µL β-mercaptoethanol + Amount950 µL 2x Laemli Buffer

Water up to Amount15 µL

Boil atTemperature95 °C before loading  Duration00:00:15

15s
Add Amount10 µL of ladder (Precision Plus Protein - Dual Color Standards)

Run at 120-150 volts Duration01:00:00

1h
Activate PVDF membrane in methanol
Soak filter paper in Towbin Buffer
Equilibrate gel in Towbin buffer Duration00:10:00

10m
Semi-dry transfer
90' (<50KDa) or 120' (>50KDa)
Mount sandwich (paper-membrane-gel-paper)
45 mA/gel (constant current)
Cut out LEFT UPPER corner of the membrane
Block membrane with 5% BSA in PBS 0.1% Tween (PBST) for Duration00:30:00

30m
Add primary antibody in BSA-PBST and incubate overnight Duration18:00:00 at Temperature4 °C

18h
Wash 3x with PBST for Duration00:05:00

5m
Add HRP secondary antibody in BSA-PBST and incubate forDuration01:00:00 at room temperature on a shaker

1h
Wash 3x with PBST forDuration00:05:00

5m
Add 500 µL ECL (enhanced chemilumescent) per membrane strip
Protocol references
https://www.ptglab.com/news/blog/lysate-preparation-why-is-ripa-buffer-best-for-western-blot/

https://docs.abcam.com/pdf/protocols/sample-preparation-for-western-blot.pdf
RIPA buffer is useful for whole cell extracts and membrane-bound proteins, and may be preferable to NP-40 or Triton X-100-only buffers for extracting nuclear proteins. It will disrupt protein-protein interactions and may therefore be problematic for immunoprecipitations and pull-down assays.

https://www.usbio.net/protocols/immunoprecipitation


  • We recommend using 1.0 mL of RIPA Lysis Buffer to lyse 0.5 to 5 x 10E7 adherent mammalian cells.
  • 1mL of buffer per 75cm2 flask containing 5 × 10ˆ6 HeLa or A431 cells.


RIPA buffer 100mL
50mM Tris HCl, PH 7.4 5mL (1M stock)
150mM NaCl 5mL (3M stock)
1% Triton X-100 or NP-40 1 mL
0.1% SDS 1mL (10% supply center solution)
1mM EDTA 0.2 mL (0.5M stock)
10mM Naf 0.042g (@L5P1 chemical room)
0.5% Sodium deoxylcholate 0.5g (@L5P1 chemical room)
Add ddH2O to 1000ml
Add PMSF to a final concentration of 1mM and any other protease inhibitors immediately before use.
Add 1 uL Pierce™ Universal Nuclease per 1mL




4 x SDS sample buffer For 1000ml
12% SDS 120g
25% Glycerol 250ml
150 mM Tris.HCl (pH 7.0 1M stock) 150ml
0.03% Bromophenol Blue 300mg
20% β-mercaptoethanol 200ml
Add ddH2O to 50ml, aliquot and store at -20°C
20% β-mercaptoethanol, (or 500 mM DTT replaced) should be added freshly before use.


Nonidet P-40 (IGEPAL® CA-630) 0.5%


Pierce™ Universal Nuclease for Cell Lysis added to RIPA NP40 1% buffer
0.1uL nuclease per 1 mL buffer = 25U/mL [final]
https://assets.thermofisher.com/TFS-Assets/LSG/certificate/Certificates-of-Analysis/00492617_88700.pdf
