Quantum-Enhanced Optical Monitoring of Bone Marrow–Derived and Pluripotent Stem Cells at 1 µm Resolution Using Squeezed-Light Interferometric Microscopy
- Luis-Francisco Acevedo-Hueso1
- 1Quantum Medical Diagnostics
Protocol Citation: Luis-Francisco Acevedo-Hueso 2026. Quantum-Enhanced Optical Monitoring of Bone Marrow–Derived and Pluripotent Stem Cells at 1 µm Resolution Using Squeezed-Light Interferometric Microscopy. protocols.io https://dx.doi.org/10.17504/protocols.io.kxygx81bzv8j/v1
License: This is an open access protocol distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited
Protocol status: Working
We use this protocol and it's working
Created: February 10, 2026
Last Modified: February 10, 2026
Protocol Integer ID: 242956
Keywords: Stem Cells, Quantum imaging , Lasers, Optics, Matlab, Python , Image sensors , optical monitoring of bone marrow, optical metrology in regenerative medicine, light interferometric microscopy, enhanced interferometric microscopy platform, monitoring mesenchymal stem cell, interferometric microscopy platform, microscopy optic, cell imaging, mesenchymal stem cell, enhanced optical metrology, enhanced optical monitoring, stem cell, na microscopy optic, pluripotent stem cell, squeezed illumination source, cell monitoring, phase sensitivity improvement beyond the shot, induced stem cell, µm resolution, derived stem cell, refractive index sensitivity, µm spatial resolution, zehnder interferometer
Disclaimer
The views and opinions expressed in this manuscript are those of the authors and do not necessarily reflect the official policy or position of Quantum Medical Diagnostics or the affiliated academic institutions. The experimental data and analysis presented herein are intended solely for research and educational purposes. The study’s findings should not be interpreted as clinical advice or used as a substitute for professional medical judgment. Any reference to specific products, technologies, or institutions is for informationalpurposes only and does not constitute an endorsement or recommendation .All experiments involving biological materials were performed in accordance with institutional guidelines and relevantregulatory standards.
Abstract
We report the experimental implementation of a quantum-enhanced interferometric microscopy platform for monitoring mesenchymal stem cells (MSCs), induced pluripotent stem cells (iPSCs), and bone marrow–derived stem cells (BMSCs) at 1 µm spatial resolution. A 5.1 dB quadrature-squeezed illumination source was integrated into a phase-stabilized Mach–Zehnder interferometer coupled with high-NA microscopy optics and sCMOS detection. The system achieves a 1.76× phase sensitivity improvement beyond the shot-noise limit (SNL), corresponding to a 2.8× signal-to-noise ratio enhancement in live-cell imaging. Sub-micron refractive index sensitivity (5.2 × 10⁻⁴ RIU) enabled early detection of mitochondrial remodeling and cytoskeletal disorganization in differentiating and stress-induced stem cells. These results demonstrate the translational potential of quantum-enhanced optical metrology in regenerative medicine and stem cell monitoring.
Attachments
Materials
Cell Sources
- Human Hematopoietic Stem Cells (HSCs): Primary HSCs were obtained from consenting donors under IRB-approved protocols and processed according to institutional guidelines.
- Cancer Cell Line: MDA-MB-231 human breast cancer cells were cultured under Biosafety Level 2 (BSL-2) conditions in compliance with institutional biosafety regulations.
Cell Culture Reagents
- Dulbecco’s Modified Eagle Medium (DMEM) or appropriate HSC expansion medium
- Fetal Bovine Serum (FBS), heat-inactivated
- Penicillin–Streptomycin (100 U/mL, 100 µg/mL)
- L-glutamine (2 mM)
- Phosphate-buffered saline (PBS), sterile
- Trypsin-EDTA solution (0.05%)
- Mitochondrial membrane potential indicator (when applicable for validation experiments)
Optical and Spectroscopy System Components
- Laser Source: 1064 nm single-frequency Nd:YAG laser (linewidth <1 kHz)
- Auxiliary alignment laser (780 nm)
- Optical isolators and beam expanders
- Polarizing beam splitters and waveplates
- Periodically Poled KTiOPO₄ (PPKTP) crystal (for squeezed-light generation, if applicable)
- High-stability interferometric microscope platform
- Vibration-isolated optical table
Detection and Acquisition
- sCMOS Camera: Andor Zyla 4.2 PLUS
- Quantum Efficiency (QE): 82%
- Median read noise: 1.0 e⁻ rms
- Frame rate: 100 fps
- Balanced homodyne detection module (for phase-resolved measurements)
- Data acquisition workstation with high-speed frame grabber
Data Processing and Analysis
- MATLAB / Python-based signal processing environment
- Fourier-domain analysis tools for Power Spectral Density (PSD) computation
- Phase unwrapping and noise-filtering algorithms
Troubleshooting
Safety warnings
- Laser and Optical Safety: Experiments involve high-intensity laser illumination (up to 100 μJ/s per sample); proper eye protection and beam containment are required.
- Microwave Exposure: Quantum sensing uses 2.87 GHz microwaves; avoid direct exposure to personnel and follow institutional safety protocols.
- Biological Materials: Human hematopoietic stem cells and cancer cell lines must be handled under appropriate biosafety level conditions (BSL-2).
- Phototoxicity: Long-term live-cell imaging may induce phototoxic effects; maintain low exposure and verify cell viability.
- Chemical Hazards: Use caution with GelMA, photoinitiators, and fluorescent dyes; handle according to MSDS guidelines.
- Electrical Equipment: Ensure proper grounding and calibration of all optical and electronic instruments to prevent hazards.
Ethics statement
Stem cell testing was conducted using a quantum-enhanced interferometric spectroscopy platform operating at 1064 nm. The system enabled non-invasive, label-free characterization of cellular microstructure, mitochondrial dynamics, and early apoptotic signatures. High-sensitivity detection was achieved through low-noise sCMOS acquisition, allowing precise phase-resolved measurements under reduced photon flux conditions. This approach ensured robust quantitative assessment of stem cell viability, metabolic state, and structural integrity while preserving cellular physiology.
All experiments involving stem cells were performed in full compliance with institutional governance standards and received approval from the appropriate Institutional Review Board (IRB). Cells were obtained from consenting donors under formally approved protocols, and all procedures were conducted in alignment with the principles outlined in the Declaration of Helsinki. The MDA-MB-231 cancer cell line was handled strictly under institutional Biosafety Level 2 (BSL-2) regulations. No direct human or animal subject interventions were performed as part of this study. All experimental activities adhered to established ethical frameworks governing laboratory safety, stem cell research, and responsible conduct of research.
Protocol references
1. C. M. Caves, “Quantum-mechanical noise in an
interferometer,” Phys. Rev. D 23, 1693–1708 (1981).
2. R. Schnabel, “Squeezed states of light and their
applications,” Phys. Rep. 684, 1–51 (2017).
3. M. A. Taylor and W. P. Bowen, “Quantum metrology and
its application in biology,” Phys. Rep. 615, 1–59 (2016).
4. V. Giovannetti et al., “Advances in quantum
metrology,” Nat. Photonics 5, 222–229 (2011).
5. J. Aasi et al., “Enhanced sensitivity of the LIGO
gravitational wave detector by using squeezed states,” Nat. Photonics 7,
613–619 (2013).
6. B. J. Lawrie et al., “Quantum sensing with squeezed
light,” ACS Photonics 6, 1307–1318 (2019).
7. P. Andrecka et al., “Structural dynamics of
mitochondria,” Biophys. J. 109, 1–10 (2015).
8.T. Wilson, “Confocal microscopy,” Academic Press
(2011).
9. E. Betzig et al., “Imaging intracellular fluorescent
proteins,” Science 313, 1642–1645 (2006).
10. S. W. Hell, “Nanoscopy with focused light,” Nat.
Methods 6, 24–32 (2009).
11. Y. Shih, “Entangled photons,” IEEE J. Sel. Top.
Quantum Electron. 9, 1455–1467 (2003).
12. M. Aspelmeyer et al., “Quantum optomechanics,” Rev.
Mod. Phys. 86, 1391–1452 (2014).
13. B. Saleh and M. Teich, Fundamentals of Photonics,
Wiley (2007).
14. D. Meschede, Optics, Light and Lasers, Wiley
(2017).
15. J. Pawley, Handbook of Biological Confocal
Microscopy, Springer (2006).
16. H. Rubinsztein-Dunlop et al., “Roadmap on structured
light,” J. Opt. 19, 013001 (2017).
17. M. Padgett and R. Bowman, “Tweezers with a twist,”
Nat. Photonics 5, 343–348 (2011).
18. L. Pezzè et al., “Quantum metrology with nonclassical
states,” Rev. Mod. Phys. 90, 035005 (2018).
19. C. Gerry and P. Knight, Introductory Quantum
Optics, Cambridge (2005).
20. A. Ashkin, “Optical trapping and manipulation,” Nobel
Lecture (2018).
