Abstract
This protocol outlines a small molecules based, 2D differentiation method for generating high-purity human induced pluripotent stem cell-derived cardiomyocytes (hiPSC-CMs). Optimized for reproducibility across hiPSC lines, the procedure achieves robust cardiac differentiation through sequential modulation of Wnt signaling, yielding functional beating cardiomyocytes by days 7–10.
Troubleshooting
Day-3 Matrix coating of Culture Vessels
10m
Coating of culture vessels (Geltrex, Laminin-511, etc.) according to optimize protocol for hiPSC
10m
Day-3 Seeding hiPSCs
3d
Passage hiPSCs as single cells using Accutase or 1x TrypLE after 1x PBS(-) wash
Seed hiPSCs on Matrix-coated 6-well plates at a density of 4x10^5 cells/well in E8 medium supplemented with Concentration10 micromolar (µM) ROCK inhibitor for the first Duration24:00:00 .
Incubate in a hypoxia incubator (Concentration5 % CO2 , Concentration5 % O2 , Temperature37 °C ).
Change the medium to E8 without ROCK inhibitor after Duration24:00:00 , and continue daily media changes until the cell density reachesConcentration90-95 % (approximately 3-4 days). *Never reach full confluency


hiPSC in E8 (day4) before differentiation, 90% confluency

3d
Critical
Day 0-21 Cardiac Differentiation
1w 2d
Day 0 (Priming): Change the medium to Amount2 mL /well of Cardiac: priming medium (RPMI 1640 + B27 Minus Insulin + CHIR-99021). Use a CHIR concentration between Concentration5-10 micromolar (µM) depending on the individual hiPSC line.
Day 1: Add Amount4 mL basal Differentiation medium/well (B27-minus insulin, w/o CHIR-99021) without removing the previous Cardiac: priming medium.
1d
Day 3 (Induction): Remove the basal Differentiation medium and add Amount4 mL of Cardiac: induction medium/well (RPMI 1640 + B27 Minus Insulin + IWR-1-endo). Use Concentration5 micromolar (µM) IWR-1-endo for our iPSC.
2d
Day 5: Add Amount4 mL basal Differentiation medium/well (B27-minus insulin, w/o IWR-1-endo) without removing the previous Cardiac: induction medium.
Day 7: Remove Differentiation medium and replace with Amount2-3 mL Maintenance medium (RPMI 1640 + B27)

Day 8: Remove Maintenance medium and replace with Amount2-3 mL Maintenance medium (RPMI 1640 + B27) Beating cells should be observed around days 7-10.
Days 9-14: Change Maintenance medium Amount3 mL every Duration48:00:00 .

2d
Days 9-12 (Optional Lactate Selection): If desired, perform metabolic selection. Replace Maintenance medium with Amount2 mL Lactate Selection medium/well (RPMI 1640 w/o glucose + CDM3 supplement + Sodium DL-lactate Amount50 µL ). Check for cell death and replace Lactate Selection medium as needed. After Duration24:00:00 , revert to Maintenance medium if a high proportion of beating hPSC-CMs is observed.
1d
Days 15-21: Perform media changes Amount3-5 mL every Duration24:00:00 to Duration48:00:00 with Maintenance medium depends on the color (yellowish: metabolites such as lactate) of medium.

hiPSC-CMs (d20, 1 day Lactate selection) Yield: 146.2 Mio from 18 wells of 6-well plate

3d
Notes
Ensure that all steps are performed with sterile techniques. Optimize CHIR concentration (5-10 µM) for each cell line. Be gentle during cell resuspension to avoid osmotic shock and shear stress.
