Abstract
This protocol describes a reproducible method to fabricate gold‑nanoparticle‑decorated laser‑induced graphene (LIG) electrodes via electrochemical deposition.
Troubleshooting
Overview
This protocol describes the process of gold electrodeposition on laser-induced graphene (LIG) electrodes by the chronoamperometry technique using a MultiPalmSens4. Figure 1 depicts the process. The time must be changed according to the number of samples you have. The resulting LIG/Au electrode is suitable for biosensing applications, including pathogen detection, enzymatic sensing, and aptamer-based assays.


Figure 1. Electrodeposition of Laser Induce Graphene Electrodes


Materials and reagents
  • Kapton film (electrical grade polyimide film, 0.0050″ thick)
  • Chemical-resistant polyvinyl chloride (PVC) sheets (1/16” thick)
  • Metal alloy tape
  • Lacquer (passivation coating)
  • Deionized water (DI)
  • Isopropyl alcohol (IPA)
  • Gold(III) chloride trihydrate (HAuCl₄·3H₂O)
  • Sulfuric acid (H₂SO₄), 1 N (Note: 1 N H₂SO₄ corresponds to 0.5 M H₂SO₄ because H₂SO₄ is diprotic; see preparation notes below.)
  • Silver/silver chloride (Ag/AgCl) reference electrode
  • Gold-wire counter electrode
  • Female USB 2.0 (Type A) connectors
Equipment and software
  • Universal Laser System (VLS3.60) and CorelDRAW (Corel Corporation)
  • Potentiostat: Multi PalmSens4 (PalmSens BV, Houten, The Netherlands) with MultiTrace software.
  • Magnetic stirrer (capable of 500 rpm) and standard three-electrode cell stand.
  • Standard laboratory glassware, pipettors, and safety equipment.
Platform fabrication (LIG)
  • Design a three-electrode layout (working, reference, counter) in CorelDRAW
  • Laser inscription settings: distance from lens to sample surface = 5.0 cm; one scan; burn-in power pulse = 40 ms; 75% pulses per inch; burn-in speed = 1000. (Adjust as needed for your laser model.)
  • Apply metal tape at the electrode pads to serve as robust bonding pads and to protect LIG during electrical connections.
  • Apply a thin layer of lacquer as passivation over the electrode shafts, leaving the active working area exposed.
  • Rinse electrodes briefly with DI water, allow to dry, and store in a dust-free container until use.
Gold Electroplating Solution Preparation
5.0 mM HAuCl₄ prepared in 0.5 M H₂SO₄.
Note: if using 1 N H₂SO₄ stock (≈0.5 M), the 1 N solution can be used directly as the supporting electrolyte and diluted accordingly when preparing the final plating solution
Equipment Setup
  • Assemble a three-electrode cell: LIG working electrode (immersed working area exposed to solution), Ag/AgCl (3 M KCl) reference electrode, and a Pt-wire counter electrode (or a gold wire if preferred for charge balance — ensure consistent method across experiments). Connect to the Multi PalmSens4 potentiostat.
  • Place the cell on a magnetic stirrer and set stirring to 500 rpm (continuous stirring during deposition).
Gold electrodeposition
  • Using the chronoamperometry technique, set a constant potential of −0.90 V (vs Ag/AgCl) for 240 s (4 minutes).
  • Ensure the working area is fully and reproducibly immersed in the plating solution.
  • After deposition, immediately remove the electrode and rinse thoroughly with DI water.
  • Optionally, perform additional characterization (SEM, EDX, or electrochemical impedance spectroscopy) if instrumentation is available

💡 Tips
Safety (acid handling): When preparing or diluting sulfuric acid, always add acid to water (never water to acid). Use appropriate PPE: acid-resistant gloves, lab coat, eye protection, and work in a fume hood when handling concentrated acids.
Protocol references
Tang, Y., Casso Hartmann, L., Bahamon Pinzon, D., Am Moreira, G., Vanegas, D., & S McLamore, E. (2022). Electrochemical analysis of laser-inscribed graphene electrodes using cyclic voltammetry (ferri/ferrocyanide redox couple) v2. Springer Science and Business Media LLC. https://doi.org/10.17504/protocols.io.4r3l27q7jg1y/v2

Rauf, S., Lahcen, A. A., Aljedaibi, A., Beduk, T., Ilton de Oliveira Filho, J., & Salama, K. N. (2021). Gold nanostructured laser-scribed graphene: A new electrochemical biosensing platform for potential point-of-care testing of disease biomarkers. Biosensors and Bioelectronics, 180, 113116. https://doi.org/10.1016/j.bios.2021.113116
