Core Processing and Root Washing Protocol
  • Grady Welsh1,
  • Lara Roelofs1,
  • Shersingh Joseph Tumber-Dávila1
  • 1Dartmouth College
Grady Welsh
Icon indicating open access to content
QR code linking to this content
DOI: https://dx.doi.org/10.17504/protocols.io.bp2l68141gqe/v2
Protocol Citation: Grady Welsh, Lara Roelofs, Shersingh Joseph Tumber-Dávila 2025. Core Processing and Root Washing Protocol. protocols.io https://dx.doi.org/10.17504/protocols.io.bp2l68141gqe/v2Version created by Grady Welsh
License: This is an open access protocol distributed under the terms of the Creative Commons Attribution License,  which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited
Protocol status: Working
We use this protocol and it's working
Created: April 15, 2025
Last Modified: May 02, 2025
Protocol Integer ID: 210817
Keywords: root morphology, fine roots, soil core, sonicator, root washing protocol members of the tumber, sorting soil core, root washing protocol member, dávila lab protocol, root sorting, processing soil core, dávila lab protocols for related protocol, soil core, root scanning, cleaning root material, soil coring, root material in preparation, dávila lab, related protocol, core, soil, tumber, protocol, processing, cliff site at harvard forest, core processing, cleaning
Funders Acknowledgements:
Dartmouth College: Department of Environmental Studies
Abstract
Members of the Tumber-Dávila Lab developed this protocol for processing soil cores taken from the CLIFF site at Harvard Forest in Petersham, MA. The protocol provides guidelines for sorting soil cores and cleaning root material in preparation for root sorting. Refer to Tumber-Dávila Lab Protocols for related protocols on Soil Coring, Root Sorting, and Root Scanning.
Materials
2 mm sieve
63 µm sieve
Sieve catch pan
Tweezers
Brush
Weigh boats
Balance
Bath sonicator (ie Vevor Digital Ultrasonic Cleaner)
White plastic table mat

Troubleshooting
Before start
12-24 hours before root picking: remove soil from -22°C freezer to slowly thaw in refrigerator.
Ensure sieves, catch pans, tweezers, and brushes are clean and dry.
Soil Sieving
Carefully pour the thawed core sample from the plastic bag onto a clean 2 mm sieve and catch pan.
Sift soil through the sieve.
Use tweezers to sort roots, rocks, and leaf litter from above the sieve into 3 weigh boats.
Note
Remove any foreign objects, such as metal shards from soil coring equipment.

Gently massage clumped soil through the sieve, allowing for the roots to separate and the soil aggregates to break down and pass through the sieve. Take care not to break fine roots in the process.
Note
Expect for this process to take 30-45 minutes. For muddier samples or 0-5 cm increments, this process could take >60 minutes.


Once the remaining soil has moved through the sieve, scan the top and bottom of the 2 mm sieve for roots, rocks, and leaf litter caught on the mesh. Add these to their respective weigh boats.
Once no roots remain in the sieve, use a clean brush to brush caught soil from the top and bottom of the sieve into the catch tray with the rest of the soil.
Root Picking
Carefully pour the soil from the catch pan onto a clean white plastic sheet and evenly distribute the soil across the sheet.
Set a timer for 10 minutes. Sort through the soil using tweezers to pick out all visible root fragments that fell through the 2 mm sieve.
After 10 minutes, take a 2 minute break.
Repeat another 10 minutes of root picking.
Soil Storage
Split the soil for other analysis, such as isotopic, microbial, or other biogeochemical analyses (Part 1) and drying (Part 2). Record the wet weight (g) of both samples and refreeze (-22°C).

Note
To minimize disruption to soil biogeochemistry, both soil samples should be refrozen ASAP after sieving.


Part 1: Remove 20-30 g for biogeochemical analyses.Amount20-30 g
Label: Soil Split, Core ID, Increment, Wet Weight (g), Date
Part 2: All remaining soil.
Label: Soil, Core ID, Increment, Wet Weight (g), Date.
Leaf litter and rocks can be refrozen or immediately dried.
Root Washing
Place the sorted roots over a clean 63 µm sieve.
Gently rinse the roots using deionized water over the sink catch tray using low pressure and massaging the roots gently if necessary. Multiple rounds of rinsing may be necessary.
Note
Work gently to avoid breaking fragile roots and root tips. This should take 1–2 minutes for small samples and <5 minutes for a 0-5 cm increment.

Remove washed roots from sieve and place in weigh boat. For deeper cleaning of fine roots, continue to Step 14. Otherwise, continue to Step 18.
Root Sonication (Optional)
To aid in removing any soils adhering to the roots, roots can be washed in a sonicator bath during the root washing process. The sonicator helps to shake off any soils stuck to the roots that remain after the initial washing process.
Use tweezers to move roots to a sonicator bath filled with deionized water.

Note
For best results, the sonicator should be filled fairly full.

Turn on the sonic power button (NOT the temperature one), and let it run for 5 minutes.

Note
For those exposed to sonicator frequently in close proximity, hearing protection should be worn.

Remove clean roots from sonicator bath and place in weigh boat.
Note
After gathering large root clumps, it may be helpful to pour sonicator water into a clean 63 µm sieve to gather any remaining washed roots.

Root Storage
Roots can be immediately sorted (See Tumber-Dávila Workspace: Root Sorting Protocol), stored up to a week in a fridge (4°C), or long-term in the freezer (-22°C).
