Feb 23, 2026
CFTR Long Read Sequencing Protocol using Oxford Nanopore Technology
- Nada EL Makhzen1,
- Alexandre Bokhobza2,
- Anne-Flore Hämmerli1,
- Jean-Sébastien ougier1,
- Hugues Abriel1
- 1Ion Channels and Channelopathies Laboratory, Institute for Biochemistry and Molecular Medicine, University of Bern, Bühlstrasse 28, 3012 Bern, Switzerland.;
- 2Department of Physiology, University of Bern, Switzerland.
Protocol Citation: Nada EL Makhzen, Alexandre Bokhobza, Anne-Flore Hämmerli, Jean-Sébastien ougier, Hugues Abriel 2026. CFTR Long Read Sequencing Protocol using Oxford Nanopore Technology . protocols.io https://dx.doi.org/10.17504/protocols.io.ewov1o7y7lr2/v1
License: This is an open access protocol distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited
Protocol status: Working
We use this protocol and it's working
Created: February 08, 2023
Last Modified: February 23, 2026
Protocol Integer ID: 76645
Keywords: Cystic Fibrosis, CFTR, Long-read sequencing, Oxford Nanopore Technology, cftr gene, entire cftr gene, fragments of the cftr gene, accurate cf carrier screening in african population, gene cftr, facilitating accurate cf carrier screening, identifying diverse cftr variant, diverse cftr variant, genetic laboratory, advantageous for genetic laboratory, using oxford nanopore technology, cystic fibrosi, oxford nanopore technology, read oxford nanopore technology, cftr long, genetic autosomal recessive disorder, sequencing protocol, cf, mk1c device
Abstract
Cystic fibrosis (CF) is a genetic autosomal recessive disorder, commonly associated with European populations, with insufficient awareness in African populations. Whole-gene CFTR sequencing is effective for identifying diverse CFTR variants, facilitating accurate CF carrier screening in African populations. The proposed method uses long-read Oxford Nanopore Technologies to sequence the entire CFTR gene. This involves amplifying ~25Kb fragments of the CFTR gene using specially designed long-range PCR primer pairs, followed by barcoded library preparation and sequencing with ONT's R10.4 flow cells and the Mk1C device. This approach is especially advantageous for genetic laboratories with limited resources, due to its cost-effectiveness and relative ease of implementation.
Guidelines
Blood collection for this protocol requires prior approval by the users' Institutional Ethics Board or equivalent ethics committee.
Troubleshooting
1) DNA Extraction using puregene blood kit (Cat.#158023)
Processing
1ml blood samples:
Things to do before starting:
- Work with fresh blood samples collected in an EDTA tube (if working with frozen blood, thaw the sample quickly in a 37°C water bath with mild agitation and store it on ice before beginning the procedure ).
- Preheat the water bath to 65°C for use in step 4.
- Optional: Preheat the water bath to 37°C for use in step 3.
1-1) Procedure
- Dispense 3 ml of RBC Lysis Solution into a 15 ml falcon centrifuge tube.
- Add 1 ml whole blood, and mix by inverting 10 times.
- Incubate for 5 min at room temperature (15–25°C). Invert at least once during the incubation.
- Centrifuge for 2 min at 2000x g to pellet the white blood cells.
- Carefully discard the supernatant by pipetting or pouring, leaving approximately 70 µl of the residual liquid and the white blood cell pellet.
- Vortex the tube vigorously to resuspend the pellet in the residual liquid. Vortexing greatly facilitates cell lysis in the next step.
Note
The pellet should be completely dispersed after vortexing.
- Add 1 ml Cell Lysis Solution, and pipet up and down to lyse the cells or vortex vigorously for 10 sec.
Note
Usually, no incubation is required; however, if cell clumps are visible, incubate at 37°C until the solution is homogeneous.
- Optional: If RNA-free DNA is required, add 5 µl, RNase A Solution, and mix by inverting 25 times. Incubate for 15 min at 37°C.
Then incubate for 3 min, on ice to quickly cool the sample.
- Add 300 µl, Protein Precipitation Solution, and vortex vigorously for 20 sec. at high speed.
- Centrifuge for 5 min at 2000 x g
Note
The precipitated proteins should form a tight, dark brown pellet. If the protein pellet is not tight, incubate on ice for 5 min and repeat the centrifugation.
- Pipet 1 ml isopropanol into a clean 15 ml tube and add the supernatant from the previous step by pouring it carefully.
Note
Be sure that the protein pellet is not dislodged during pouring.
- Mix by inverting gently 50 times (Do not vortex) until the DNA is visible as threads or a clump.
- Centrifuge for 3 min at 2000 x g (The DNA may be visible as a small white pellet).
- Carefully discard the supernatant, and drain the tube by inverting on a clean piece of absorbent paper, taking care that the pellet remains in the tube.
- Add 1 ml of 70% ethanol and invert several times to wash the DNA pellet.
- Centrifuge for 1 min at 2000 x g
- Carefully discard the supernatant. Drain the tube on a clean piece of absorbent paper, taking care that the pellet remains in the tube. Air dry the pellet for 5-10 min.
Note
The pellet might be loose and easily dislodged. Avoid over-drying the DNA pellet,
as the DNA will be difficult to dissolve.
- Add 100 µl DNA Hydration Solution and vortex for 5 sec. at medium speed to mix.
- Incubate at 65°C for 1h to dissolve the DNA.
- Incubate at room temperature overnight with gentle shaking. Ensure that the tube cap is tightly closed to avoid leakage. Samples can then be centrifuged briefly and transferred to a storage tube (1.5 ml DNA LoBind Tube).
Note
DNA should be stored at -20°C for long-term use.
2) Amplification ( PCR using takara Ex Premier™ DNA Polymerase Dye plus (cat.#RR371A))
11 overlapping PCR products to cover the whole CFTR gene
| A | B | C | D | |
| Sequence (5'->3') Forward | Sequence (5'->3') Reverse | Primer pair size | ||
| CFTR Primer pair 1 | AAGTGAAGTTCCTGCTTTGCTTTGGGTAAG | TGGGTTCTTGGTGGCATTTTAACCCTTTTT | 22.803 kb | |
| CFTR Primer pair 2 | GTCCCCATTCCAGCCATTTGTATCCTTAGA | AGTCCCTAGATAGCCAATCACAGGAAGAGA | 23.74 kb | |
| CFTR Primer pair 3 | CAGCAGCCAGATAGATGCAACATTGTCTTT | CACAATCCCTTCTTCAAGGCGACCTAGTAT | 21.181 kb | |
| CFTR Primer pair 4 | AAGAGACCAAATTGCCGAGGCATCATTTAG | GTCCAAGATAGTGGGAAAAGCAAGAAGCAA | 21.115 kb | |
| CFTR Primer pair 5 | TAGAATTTTGCATCACTGGATGCCCTTGAC | AATAAGTGTGGTAGGAGCAGAGGGAACAAG | 20.963 kb | |
| CFTR Primer pair 6 | GTAGAATGAAATGAGCCTGGACCCAAGAGA | ATCTGGATTTGAACCCAACCTCCACCATTA | 26.089 kb | |
| CFTR Primer pair 7 | AGATCTCCTCCTCAGTCACACAGA | GGAGCTGTTAAGGGAGACAAGGAA | 20.492 kb | |
| CFTR Primer pair 8.1 | GTGTTGGAGCTGCCATTTCG | TATGGCCCACAGGACACATC | 10.41 kb | |
| CFTR Primer pair 8.2 | GTCTGTGGTAAGAGCCCTGC | CCTTTCCCACCCACTGAGAC | 10.635 kb | |
| CFTR Primer pair 9 | TGCCACCCCTTTGCTTTGCT | TACTTAGTTCTCTGTGCCTGGGGTGAATTG | 23.059 kb | |
| CFTR Primer pair 10 | CTTTGATTGCTGAATGCGAATGGATGGGTA | GACAGGGACAAGTAAAGCCCCAAAATCAAG | 22.251 kb |
CFTR Primer Pairs
- Prepare 11 PCR tubes per patient on ice, using the following mix:
| A | B | |
| Reagent | Volume | |
| Takara Ex Premier™ DNA Polymerase Dye plus (cat.#RR371A) | 12.5 µl | |
| Nuclease free water | 10.5 µl | |
| Forward primer at 10 μM | 0.5 µl | |
| Reverse primer at 10 μM | 0.5 µl | |
| gDNA (100ng/μl) | 1 µl | |
| Total | 25 µl |
Note
Pipette up and down, and if needed spin down briefly.
- Amplify using the following thermocycler conditions:
| A | B | C | |
| Steps | Temperature | Time | |
| Initial Denaturation | 94°C | 1 min | |
| For 27cycles (Annealing and extension in one step) | 98°C | 10 sec. | |
| 68°C | 13 min | ||
| Hold | 4°C | ∞ |
Thermocycler condition for PCR 1, 2, 3, 4, 5, 6, 7, 9 and 10
| A | B | C | |
| Steps | Temperature | Time | |
| Initial denaturation | 94°C | 1 min | |
| For 27 cycles (Annealing and extension in one step) | 98°C | 10 sec. | |
| 68°C | 10 min | ||
| Hold | 4°C | ∞ |
Thermocycler condition for PCR 8-1 and 8-2
3) DNA visualization in agarose gel electrophoresis
- Prepare a 0.4% Tris Acetate EDTA (TAE) agarose gel.
- Load 5 μl of each amplified product.
Note
A ladder with a 1 kb size needs to be added to one of the wells as a reference for analysis.
- Run the gel at 160V for 30 min.
- Visualize the DNA using a gel imaging device.
Note
Some unspecific band products may appear during amplification and be visible in the agarose gel; however, if their intensity remains below the target range, it is considered acceptable, since the next section steps will help get rid of these bands.
4) PCR product Purification
- Transfer each PCR-amplified product to a DNA LoBind Tube (11 tubes per patient).
- Resuspend the AMPure Beads (Beckman coulter, Cat.#A63881) by vortexing, and add 1.8 volume of AMPure beads for 1 volume of PCR product.
- Mix the solution by pipetting up and down, be gentle, and avoid making bubbles.
- Incubate for 5 min at RT, and prepare fresh 80% ethanol during this time.
- Place on a magnetic rack for at least 2 min until the liquid becomes clear.
- Remove the supernatant without disturbing the beads.
- Add 200 µl of freshly prepared 80% ethanol without disturbing the pellet.
- Remove ethanol.
- Repeat the previous step.
- Eliminate residual ethanol (use a new pipette tip to aspirate ethanol in the bottom of the tube).
- Remove from the magnet and elute with 40 µl of Elution Buffer (10 mM Tris pH8.0 + 50 mM NaCl). Incubate for 2 min at RT.
- Place on a magnetic rack for 1 min (until the eluate is clear).
- Aspirate and keep eluate (35-37 µl) without taking the beads.
- Remove and retain the eluate (keep on ice).
Note
- DNA can be kept at 4°C overnight.
- Quantify the DNA.
5) Sequencing using Rapid Barcoding Kit V14 (SQK-RBK114.24)
For each PCR-amplified purified product (11 amplicons for each individual) input, transfer the following quantity depending on the number of individuals:
- 50 ng gDNA per PCR- amplified purified product for >4 individuals.
- 200 ng gDNA per PCR- amplified purified product for <4 individuals.
Note
Sometimes low quality obtained during purification makes it difficult to get 50ng gDNA per PCR-amplified purified product; in such cases, <50ng gDNA input per PCR-amplified purified products might be a solution; just be sure to have the same quantity input for all individuals.
Prepare the DNA in nuclease-free water:
- Transfer the gDNA into 0.2 ml thin-walled PCR tubes (11 tubes per individual).
- Adjust the volume to 10 µl with nuclease-free water.
- Pipette mix the tubes 10-15 times to avoid unwanted shearing.
- Spin down briefly in a microfuge.
- In each 0.2 ml thin-walled PCR tube:
| A | B | |
| Reagent | Volume per Sample | |
| gDNA | 10 µl | |
| Rapid Barcodes (RB01-24) one for each patient | 1 µl | |
| Total | 11 µl |
Note
Pipette up and down to ensure the components are mixed.
- Incubate the tubes as follows:
| A | B | |
| Temperature | Time | |
| 30°C | 2 min | |
| 80°C | 2 min |
Note
After incubation, briefly put the tubes on ice to cool.
- Pool all barcoded samples in a 1.5 ml Eppendorf DNA LoBind tube.
- Resuspend the AMPure XP Beads (Beckman couler, Cat.#A63881) by vortexing.
- Add an equal volume of resuspended AMPure XP Beads to the entire pooled barcoded sample from step 10, mix by pipetting up and down, and avoid making bubbles.
| A | B | |
| Volume per sample | Volume of AMPure XP Beads to be added | |
| 11 µl | 11 µl |
- Incubate for 5 min at room temperature, and prepare at least 3 ml of fresh 80% ethanol during this time.
- Place on a magnetic rack for at least 2 min until the liquid becomes clear.
- Remove supernatant without taking beads.
- Add 1.5 ml of 80% of freshly prepared ethanol without disturbing the pellet.
- Remove ethanol.
- Repeat the previous step.
- Eliminate residual ethanol (use a new pipette tip to aspirate ethanol in the bottom of the tube).
- Remove from the magnet and elute with 15 µl of Elution Buffer (EB). Incubate for 10 min at room temperature.
- Place on the magnet for at least 2 min until the eluate becomes clear.
- Aspirate and keep eluate 15 µl without taking the beads into a clean Eppendorf DNA LoBind tube.
Note
Quantify 1 µl of the eluted sample.
- Transfer 11 µl of the sample into a clean 1.5 ml Eppendorf DNA LoBind tube.
Note
Transfer a maximum of 800 ng of the DNA library.
- In a fresh 1.5 ml Eppendorf DNA LoBind tube, dilute the Rapid Adapter (RA) as follows and pipette mix:
| A | B | |
| Reagent | Volume | |
| Rapid Adapter (RA) | 1.5 µl | |
| Adapter Buffer (ADB) | 3.5 µl | |
| Total | 5 µl |
- Add 1 µl of the diluted Rapid Adapter (RA) to the barcoded DNA.
- Mix gently by flicking the tube, and spin down.
- Incubate the reaction for 5 min at RT.
Note
After the incubation, store your sample on ice, until ready to load.
6) Library Loading on R10.4.1 flow cell (FLO-MIN114) using Flow Cell Priming Kit (EXP-FLP004)
- Perform a flow cell check to determine the number of available pores (for the flow cell, the number of pores should be >800 pores).
6) Library Loading on R10.4.1 flow cell (FLO-MIN114) using Flow Cell Priming Kit (EXP-FLP004)
Material: - Using Flow Cell Priming Kit (EXP-FLP004), thaw the sequencing Buffer (SB), library Beads (LIB), Flow cell tether (FCT), and one tube of Flow cell Flush (FCF) at room temperature. Mix by vortexing and spin down.
- Prepare the flow cell priming mix, using the following reagents:
| A | B | |
| Reagents | Volume per flow cell | |
| FCF | 1,170 µl | |
| FCT | 30 µl | |
| Final volume in FCF tube | 1,200 µl |
- Open the priming pore (1) of the flow cell as displayed in the picture and:
- Set a P1000 pipette to 200 µl.
- Insert the tip into the priming port.
- Turn the wheel until the dial shows 220-230 µl, or until you can see a small volume of buffer entering the pipette tip.
Note
Visually check that there is a continuous buffer from the priming port across the sensor array.
- Load 800 µl of priming mix in the priming port (1) of the flow cell, avoiding the introduction of air bubbles. Wait for 5 min.
- Prepare the library: - Mix the LIB component in a low DNA binding tube.
- In a new tube, prepare the library for loading as follows:
| A | B | |
| Reagent | Volume per flow cell | |
| SB | 37,5 µl | |
| LIB (mixed immediately before use) | 25,5 µl | |
| DNA library | 12 µl | |
| Total | 75 µl |
- Lift the SpotOn sample port cover (2).
- Load 200 µl of priming mix via the priming port (1).
- Mix the prepared library by pipetting up and down (do not make bubbles!) and load 75 µl on the SpotON sample port (2) (different port!) drop by drop on top of the pore.
- Put back the SpotOn sample port cover and close the priming pore.
- Start sequencing.
7) Data Analysis
- Stop sequencing, after a maximum of 24h (it depends on how many individuals are sequenced), in our case, sequencing was stopped with an estimated N50 of ~7kb and with ~ 2.3M of generated reads.
- Data Analysis can be done using EPI2Me tools from Oxford Nanopore, or through a bioinformatic analysis pipeline using tools as described in the figure below:
- Aligned reads and detected variants can be visualised using integrative genomics viewer (IGV) (https://igv.org/app/)
